Split-type cement silo is widely used for storing cement, mineral powder and other powder materials.
Model: SNC50-SNC300
Unloading Height: 4200-6500mm
Diameter of the Silo: 3100-5300mm
Volume: 38-219m3
Related Products
Split-type Cement Silo

Split-type cement silo is a new type of silo, also called split cement silo. It is a new type of silo for factory and modular production and processing, which can be used after being assembled and connected with bolts after arriving at the construction site. All parts of the silo are completed by mechanical processing, which gets rid of the rough defects caused by manual welding and gas cutting caused by traditional on-site production, and has the advantages of beautiful appearance, short construction period, convenient installation, centralized transportation without size restrictions, reuse after use, and not affected by site conditions.

Get Price Quote
Contact Us
Split-type Cement Silo
Main Features of Split-type Cement Silo
The diameter of the cement silo can be arbitrarily designed according to needs, and the storage capacity is large;
All silos implement standard modularization, short production cycle.
Reliable sealing structure: using special sealing strips, it can withstand the test of 200 degrees high temperature. After the sealing strip is compacted, the dust automatically burrows into the small gap, which has a self-sealing effect.
Not limited by transportation, quick and convenient disassembly and assembly, long service life, can realize multiple construction site reuse, greatly saving the user's secondary investment.
The roof of the warehouse is equipped with a negative pressure dust collector to further reduce the pollution of dust to the environment and has good environmental protection.
Technical Parameters
Technical Parameters of Split-type Cement Silo
No. Model Unloading Height Diameter of the Silo Volume
1 SNC50 4200мм 3100мм 38м3
2 SNC100 4200мм 3100мм 70м3
3 SNC150 4200мм 3100мм 102м3
4 SNC200 6500мм 4400мм 147м3
5 SNC300 6500мм 5300мм 219м3
Note: Capacity in tons at a material density of 1.5 t/m3.
